Cap/Size |
L |
H |
b |
B |
M |
H1 |
|
50kg,100kg 0.05~0.3klb |
50.8(2.0) |
63.5(2.5) |
12.7(0.5) |
16.08(0.63) |
M8 1/4-28UNF |
10.16 (0.4) |
|
250kg,500kg 0.5~1.5klb |
50.8(2.0) |
63.5(2.5) |
19.05(0.75) |
22.43(0.88) |
M12 1/2-20UNF |
|
|
1t /2,2.5klb |
50.8(2.0) |
63.5(2.5) |
25.4(1.0) |
28.78(1.13) |
M12 1/2-20UNF |
|
|
2.5t/ 3klb |
50.8(2.0) |
101.6(4.0) |
25.4(1.0) |
28.78(1.13) |
M20×1.5 1/2-20UNF |
15.24 (0.6) |
|
5t/ 5,10klb |
76.2(3.0) |
101.6(4.0) |
25.4(1.0) |
28.78(1.13) |
M20×1.5 3/4-16UNF |
20 (0.79) |
|
7.5t /15klb |
101.6(4.0) |
139.7(5.5) |
31.75(1.25) |
35.13(1.38) |
M24×2 1-14UNF |
31 (1.22) |
|
20klb |
127(5.0) |
177.8(7.0) |
50.8(2.0) |
54.18(2.13) |
5/4-12UNF |
39.9(1.57) |
Technical Parameter:
|
Rated Load: |
0.05/0.1/0.25/0.5/1/2.5/5/7.5/10t 50/75/100/150/200/300/500/750/1k/1.5k/2k/2.5k/3k/5k/10k/15k/20klb |
||
|
Sensitivity: |
(2.0±0.1%) mV/V |
Operating Temp.Range: |
-30~+70℃ |
|
Combined Error: |
±0.02% F.S |
Maximum Safe Over Load: |
150%F.S |
|
Creep Error(30min): |
±0.02% F.S |
Ultimate Over Load: |
300%F.S |
|
Zero Balance: |
±1% F.S |
Recommend Excitation Vol.: |
10~12V DC |
|
Temp. Effect On Zero: |
±0.02% F.S/10℃ |
Maximum Excitation Vol.: |
15V DC |
|
Temp. Effect On Span: |
±0.02% F.S/10℃ |
Sealing Class: |
IP67/IP68 |
|
Input Resistance: |
385±5Ω |
Element Material: |
Alloy/Stainless Steel |
|
Output Resistance: |
352±2Ω |
Cable: |
Length=L:2m |
|
Insulation Resistance: |
≥5000MΩ |
Citation: |
GB/T7551-2008/ OIML R60 |
|
Mode Of Connection: |
Red(Input+),Black(Input-),Green(Output+),White(Output-) |
||
